Description
Designed to out-perform and out-feature all other single impeller portable high pressure pumps, the QP205 offers significant quality features.
These include a huge 7” diameter, one piece impeller that weighs 2½ times more than impellers in other brands. The big belly body provides large water passages allowing more water to get through the pump and significantly aiding performance.
The pump will produce flows of up to 450 litres per minute and heads as high as 75 metres. Powered by a Honda GX200 four stroke engine with oil alert, low oil protection, cast iron cylinder bore in conformance with tough international environmental emission standards. The QP205 comes with anti vibration mounts, steel skids and handle as standard. Remember the golden rule, operate pump at the best efficiency point, 85% of max pump head.
- High Performance – Hydraulic design and quality components deliver more performance and capability.
- Reliability – The Honda GX200 from the world’s leading supplier, ensures your pump will start first time, every time.
- Lightweight & Portable – Lightweight, portable pumps give you the ability respond to fires quickly.
- Easy to Use – The self priming design is simple and fast to set up.
Applications:
- Fire fighting, mop up and general fire protection
- High pressure water transfer
- Spray irrigation
- High pressure spraying
- Sheep jetting
- Boom spraying
- Stock crate wash down
- Machinery wash down
Product Code | QP205 |
Pump Type | High pressure heavy duty closed impeller |
Engine | GX200 |
Displacement (cc) | 200 |
Fuel Type | Unleaded |
Oil Alert |
Yes |
Total Head (m) | 75 |
Suction Head (m) | 7.6 |
Max Discharge Capacity | 450 litres/min |
Mounting | Skids & Handle |
Discharge Port Diameter (mm) | 2x25 or 1x37.5 |
Suction Port Diameter (mm) | 50 |
Outlet | Marine grade aluminium |
Length (mm) | 492 |
Width (mm) | 383 |
Height (mm) | 432 |
Dry Weight (kg) | 23 |
